Purpose: |
|
|
Technical specifications
|
|
| Load capacity, t |
1,2
|
|
Drive type
|
manual
|
|
Lifting mechanism brake type
|
automatic/frictional
|
|
Brake stock rate
|
1,5
|
|
Height of rail lifting above gauge plane, mm, not less than
|
450
|
| Value of travel of pulley block along lifter travel, mm, not less than | 830 |
|
Handle effort during rail lifting, kgf, not exceeding
|
20
|
|
Lifter weight, kg, not exceeding
|
116
|
|
Overall dimensions, mm, not exceeding
|
|
|
- length in transport position
|
2365
|
|
- length in operation position
|
1925
|
|
- width
|
810
|
| - height above rail head | 970 |
