Purpose: |
|
|
Technical specifications
|
|
|
Engine model
|
Honda Gx 120, 1-cylinder, 4-cycle, with horizontal shaft
|
|
Cooling
|
Forced, air
|
|
Maximum torque consumption at 2500 rpm , Nxm
|
0,75
|
|
Engine start-up
|
Cord with automatic reverse
|
|
Fuel
|
petrol
|
|
Fuel tank capacity, l
|
2,5
|
|
Borer type
|
Circular, with removable multiplex cutting plates
|
|
Spindel rotary speed, rpm
|
2500-2700
|
|
Boring pass, mm
|
28
|
|
Maximum boring diameter, mm
|
22; 36
|
|
Borer feed
|
automatic
|
|
Overall dimensions, mm, not exceeding:
- length
- width
- height
|
1100
485
420
|
|
Weight without fuel, kg, not exceeding
|
48
|
