Purpose:
Heating and runoff of viscous oil products from railway tank cars.
Technical specifications
Time of heating and runoff of viscous (black) oil products at ambient temperature -40С, h | from 6 up to 10 depending on oil product type |
Drained product viscosity (for reduced crude M-100) at temperature 80С, RV | 16 |
Circulating pump: | |
- capacity, m3/h | 30 |
- outlet pressure, kg/cm2 | 6 |
- electric motor power, kWt | 11 |
Discharge pump: | |
- capacity, m3/h | 15 |
- outlet pressure, kg/cm2 | 6 |
- electric motor power, kWt | 4 |
Heat exchanging unit: | |
- thermal agent | steam |
- steam rate (maximum), kg/h | 1000 |
- steam temperature at pressure 6 kg/cm2, С | 160 |
- heating area, m2 | 43 |
Discharge tank: | |
- capacity, m3 | 0,83 |
Overall dimensions: monoblock (heat exchanging unit/discharge tank, including binding); |
|
-length, mm | 4093 |
- height, mm | 2900 |
- width, mm | 3330 |
Weight, kg | 3500 |
